Section 4: Operation
Reconnect the cables and securely
tighten to battery posts. The engine wiil
recharge the battery if the battery is still
good.
• If you suspect the batter is “dead”, or if
the battery is damaged, disconnect, and
remove it. Have it checked by a
qualified technician.
• if battery has been removed, wrap cable
terminals at end of positive cable with
electrical tape and secure the cable to
the battery bracket. This will prevent
electrical discharge.
• Before pulling the recoil starter rope,
turn the keyswitch to the RUN position.
Move the Throttle Lever away from
STOP position and set the choke as
applicable. See Engine Owner’s Manual.
Cold Weather Operation
When temperatures fall below 40'f. do
the follow'ing stops to protect your
engine and transmission from damage:
1. Refer to the Engine Owner's Manual
for motor oil specifications for cold
weather operation Use winter blend
gasoline.
2. Warm up the engine before putting it
under a load
3. Use winter-blend gasoline.
4. Use the correct weight gear oil in PTO
Power Unit 'transmission.
5. Warm up the transmission gear oil as
follows: With engine running, move
Wheel Speed Lever (Figure 4-2) to
FREEWHEEL (then block wheels so they
can't roll). putTines/PTO Clutch Lever
into DISENGAGE, then squeeze one of
the Forward Interlock Levers and shift
the WheelS/Tines/PTO Drive Lever to
FORWARD.
6 . If wheels are frozen to the ground,
melt ice with warm water.
Stopping the Engine and Tilier
1. To stop the wheels and tines, move the
Wheels/Tines/PTO Drive Lever into
NEUTRAL position and then release both
Forward Interlock Levers.
18
2. Move the engine Throttle Lever to the
STOP position. Then on electric start
models, turn the key to OFF. Remove the
key for safekeeping.
NOTE: The engine may have a separate
Throttle Control Lever and ON/OFF switch
on the engine. These controls can also be
used to stop the engine. See the Engine
Owner’s manual for information specific
to your engine.
Operating the Tiller
When first practicing, keep the Tines/PTO
Clutch Lever in DISENGAGE position and
the Wheel Speed Lever in SLOW position.
A
CAUTION
To avoid serious personai injury or
damage to equipment:
• Aiways piece Wheeis/Tines/PTO Drive
Lever in NEUTRAL before starting
engine, and before engaging wheeis,
tines or other PTO attachments.
• Be sure there are no obstacies behind
you before moving in reverse.
• Wheeis/Tines/PTO Drive Lever should
automaticaiiy return to NEUTRAL
when reieased from REVERSE
position, if it does not, move iever to
NEUTRAL
manuaiiy and discontinue
use untii you adjust the fever. See
Section 5,
Checking and Adjusting
Reverse Drive System.
• No reverse motion shouid occur if
Wheeis/Tines/PTO Drive Lever is not
heid up in REVERSE. See Section 5,
Checking and Adjusting Reverse
Drive System for adjustment steps.
Do not use filter untess property
adjusted.
• Always return to NEUTRAL and let all
motion stop before shifting to
FORWARD or REVERSE._______________
The following pages provide guidelines
for using your tiller effectively and safely
in various gardening applications. Be
sure to read Tilling Tips & Techniques, in
this Section, before you actually put the
tines into the soil.
This is a traditional standard-rotating-tine
(SRT) tiller with forward rotating tines. It
operates in a completely different manner
than counter-rotating-tine (CRT) tillers, or
from front-tine tillers.
Moving the Tiller Forward and Tilling
1 . start the engine and gradually increase
engine speed to FAST (see Starting the
Engine, this Section).
A
DANGER
The Forward Interlock Safety System is
designed for the operator’s safety. Do
not disconnect or attempt to defeat the
purpose of the system. If the system
malfunctions, immediately contact your
local
authorized dealer or the
TROY-BILT Technical Service Depart­
ment for assistance. Do not use the
tiller or the PTO power unit until the
Forward Interlock Safety System is
functioning properly. Always test the
system before using the tiller or PTO
power unit.
2. Test the Forward Interlock Safety
System. See
Testing Forward Interlock
System, this Section.
A WARNING
i
Keep away from rotating tines. Rotating
tines will cause injury.
3. When practicing, set the Depth
Regulator Lever to Travel position.
Otherwise, set the Depth Regulator Lever
to a desired depth.
4. Move Tines/PTO Clutch Lever to
ENGAGE position if you want the tines to
turn, if practicing, ieave in DiSENGAGE.
IMPORTANT: Do not move Tines/PTO
Clutch Lever to ENGAGE unless
Wheels/Tines/PTO Drive Lever is in
NEUTRAL. Tiller damage may occur!
5. To move the tiller forward and engage
the tines, squeeze and hold either Forward
Interlock Lever (Figure 4-3) against the
handlebar grip, then move the
Wheels/Tines/PTO Drive Lever down to
FORWARD position.
