Technical Summary

Flash EPROM Voltage Selector: JP8

This jumper is factory set for the type of EPROM chip installed.

JP8

+5V

1&2

+12V

2&3

JP8

o

+5-Volt

EPROM

JP8

o

+12-Volt

EPROM

Flash EPROM Read/Write Selector: JP9

This jumper selects between Normal Read/Write Protected mode and Program­

ming Enabled mode for the BIOS flash EPROM.

JP9

Normal / W. Protect

1&2

Default

Programming Enabled

2&3

■ C-

"O

©

. c_

TJ

o

CO (T)

CO (f)

o

0

Normal Read

Write Protect

Enable

Programming

4 - 3
