P/I-AP55T User's Manual
Installing a Pentium Upgrade
If yoiir mainboard has a "Socket 7" ZBF socket and Header 7 VRM
(Voltage Regulator Module) socket, you can install a Pentium up-
gr,ade processor ruiming at either 150MHz or 167MHz. The upgrade
package will consist of the Pentium CPU and the required VRM.
To install an upgrade processor, follow the instructions that come
with the upgrade. Remember to take careful precautions against static
electric discharge. The basic procedure will be as follows:
1. Turn off and discormect everything and open your system
2. Remove the existing CPU from the ZIP socket.
3. Follow the instructions that come with your upgrade kit for
installing the upgrade components.
4. Reassemble the system and turn it on to make sure everything
is working correctly.
As with any upgrade, if you are not comfortable doing the work
yourself, you may want to have your system vendor, dealer or a ser­
vice technician do the work for you. This is a particularly good idea
where expensive and easily damaged components are concerned.
2-14
