Models 664D & E666M
BUMPER ATTACHMENT
REF
No.
PART
No.
DESCRIPTION
QTY.
REF
No.
PART
No.
DESCRIPTION
QTY.
Bumper
-
OEM-290-254
5
712-0267
Nut-hex, 5/16-18*
1
1918749
Bumper ........ ...... ....... ....... ....... .
. 1
(included in hardware kit)..........
.. 4
2
777S30653
Decal - Caution.............. ........ ....... .
. 1
—
1918781
Hardware Kit; Incl. four each of
3
710-0395
Screw-hex hd., 5/16-18 x 2-1/4*
Refs. 3,4and 5........................ .
„ 1
(included in hardware kit) .............
. 4
4
736-0119
Lockwasher-5/16*
(included in hardware kit)............... . 4
