Troy-Bilt PONY E666M - Manual (Page 31)

Models 664D & E666M
ENGINE, SUPPORT BRACKETS, PULLEYS, BELTS, BELT COVER
REF.
No.
PART
No. DESCRIPTION QTY.
REF.
No.
PART
No. DESCRIPTION QTY
1 710-0539 Screw, 3/8-24x1.75 ......... ....... ....... ... 1 28 712-0267 Hex Nut, 5/16-18........ ........ ...... . .. 4
2 1917326 Bracket, Clutch Cable................ ....... ... 1 29 1186329 Hex Flange Screw, 5/16-18 x 3/4*... .. 4
3 736-0119 Lockwasher-5/16.............. ....... ....... ... 6 30 1916797 Engine Support Bracket, ieft side..... .. 1
4 710-0107 Hex Hd. Screw, 5/16-24x1/2............. ... 2 31 1916796 Engine Support Bracket, right side... .. 1
5 777S30651 Decal, Hot Surfaces/Belt Warning... ... 1 32 736-0452 Bell Washer................. ....... ....... . .. 1
6 1916659 Cover.............. ....... ....... ....... ....... ... 1 35 710-0395 Hex Hd. Screw, 5/16-18x2-1/4........... .. 5
7 712-3004A Flange Lock Nut, 5/16-18.......... ....... ... 2 36 777120942 Decaf, Stabilization....... ....... ....... . .. 1
8 1108841 Key. 3/16x1-1/2............... ....... ....... ... 1 37 1918774 Mounting Bar.............. ........ ...... . .. 2
9 GW-1138-1 Shim....... ....... ....... ....... ....... ....... ... 1 38 GW-90063 Hex Flange Screw, 5/16-18 x 1 ........ .. 4
10 619-04015 Pulley, Engine Drive................... ....... ... 1 39 710-0805 Hex Hd. Screw, 5/16-18x1-1/2*.......... .. 1
11 GW-9944 Belleviiie Washer............... ....... ....... ... 2 40 736-0275 Flat Washer, 5/16'........ ....... ....... . .. 1
12 GW-9572 Hex Hd. Screw, 5/16-24x1-1/8......... ... 1 41 1918846 Belt Guide, Pony.... ...... ....... ....... . .. 2
13 710-3103 Hex Hd. Screw, 5/16-18x2................. ... 1 42 GW-55088 Pivot Bushing.............. ....... ....... . .. 2
14 1918731 Reverse Idler Arm............. ....... ....... ... 1 43 736-0119 Lockwasher, 5/16........ ....... ....... . .. 2
15 1916535 Pulley, Reverse Idler........... ....... ....... ... 1 44 712-3010 Hex Nut, 5/16-18........ ....... ....... . .. 2
16 736-0159 Flat Washer, 5/16............................. ... 2 45 1917746 Washer, Shoulder.............................. .. 2
17 1916725 Belt Guide, Wire Formed .................... ... 1 46 1918744 Idler Arm, Forward Tiller Direction... .. 1
18 710-0117 Hex Head Screw, 5/16-24 x 1............ ... 1 47 1767754 Screw, self tapping, #10-24................. .. 1
19 1917746 Washer, Shoulder.............................. ... 1 48 1916727 Spring............................................. .. 1
20 736-3078 Washer, Flat, 1-1/8........................... ... 3 49 712-3000 Hex Locknut, 5/16-18....................... .. 1
21 1916728 Spring, Reverse Return...................... ... 1 50 GW-9090 Idler Pulley, Forward........................... .. 1
22 1916522 Transmission Pulley.......................... ... 1 51 710-0347 Screw, 3/8-16x1-3/4........................ .. 1
23 GW-1440 Support Washer............................... ... 1 52 712-0158 Hex Lock Nut, 5/16-18..................... .. 1
24 1918812 Reverse Clutch Belt........................... ... 1 53 1754128 Screw, 1/4-20x3/4........................... .. 1
25 1909404 Forward Clutch Belt........................... ... 1 54 736-0463 Flat Washer-1/4............................... .. 1
26 1900396 Self-tapping Screw, #10-32 x 1/2,.. ... 4 55 714-04029 Key, .188x 1.75................................ .. 1
27 GW-20339 Guard, Belts/Pulleys.......................... ... 1 56 1
Specify GRADE 5 if ordering part locally.
See your local authorized engine service dealer for engine parts or
service. Refer to engine nameplate for engine type and code
information.
