Models 664D & E666M
HANDLEBAR ASSEMBLY and CONTROL LEVERS
REF.
No.
PART
No. DESCRIPTION QTY.
REF.
No.
PART
No. DESCRIPTION QTY.
1 1918801 Handlebars........... ....... ....... ....... ....... 1 15 1186211 Hex Nut, 5/16-24............. ....... ....... .... 2
2 GW-9126 Grip............. ....... ....... ....... ....... ....... 2 16 GW-90064 HexHd. Screw, 3/8-16x5/8*.............. .... 2
3 777I22088 Decai, Coniroi Panel .............................. 1 17 736-0169 Lockwasher, 3/8.............................. .... 2
3A 777D05553 Decal, Model Hame/Logo....................... 1 19 725-0157 Cable Ties, Plastic............................. .... 2
4 1916784 Reverse Clutch Control Cable.................. 1 21 1114748 Round Hd. Screw, #10-32x1/2.......... .... 6
5 1186347 Height Adjustment Screw....................... 1 22 1100240 Lockwasher, #10............................. .... 2
5A GW-9955 Washer, Keyed...................................... 1 23 1186208 Hex Nut, #10-32............................. .... 2
6 1900475 Bracket, Handlebar Height Adjustment 1 24 GW-9390 Grip............................................... .... 2
7 710-0514 HexHd. Screw, 3/8-16x1*...................... 2 25 1918802 Bail, Forward Clutch Control............... .... 1
8 736-3050 Washer, Plain (flat) 3/8, S.A.E................... 2 36 GW-9853 Sems Nut....................................... .... 4
9 712-3000 Hex Locknut, 3/8-16............................ 2 36 GW-20806 Bracket, Ball Support......................... .... 2
10 746-04027 Cable, Forward Clutch Control................. 1 42 710-0599 Hex Flange Screw, self-tapping.
13 GW-9442 Wheel Gear Control and Cable Assy.......... 1 1/4-20x1/2*.............................. .... 2
14 GW-9057 Knob, Wheel Gear Control Lever.............. 1
Specify GRADE 5 if ordering part localiy.
