Models 664D & E666M
WHEEL SHAFT, ECCENTRIC SHAFT and TILLER SHAFT ASSEMBLIES
16
REF.
No.
PART
No.
DESCRIPTION
QTY.
1
721-04031
Oii Seai...... ....... ....... ....... ........ ...... .
2
9
GW-20712
Wheel Drive Clutch (cast-iron)...... .......
1
2
1909950
Retaining Ring (heavy-duty, externa!}
2
10
611-04002
Eccentric Shaft............ ....... ....... ......
1
3
GW-1166-1
Shim, 1-1/64 LD...062“ thick.................
A/R
11
GW-1442
Pin, Eccentric Shaft....................... ......
1
-
GW-1166-2
Shim, as above, but .030" thick............ .
A/R
12
GW-9055
Spring.. ......... ........... ....... ....... ......
1
-
GW-1166-3
Shim, as above, but .015" thick..............
A/R
13
721-04034
Oil Seal....................... ....... ....... ......
1
-
GW-1166-4
Shim, as above, but .010" thick.............
A/R
14
786-04001
Eccentric Shaft Lever...........................
1
4
GW-1086
Bushing............................................
2
15
710-3013
Hex Hd. Screw, 1/4-20x1/2*..............
1
5
711-04091
Wheel Shaft.......................................
1
16
741-3037
Bali Bearing.......................................
2
6
GW-9373
Hi-Pro Key, 1/4x1-5/16......................
1
17
711-04080
Tier Shaft.........................................
1
7
GW-20914
Wheel Drive Worm Gear (cast-iron)..
1
18
GW-1104
Woodruff Key, 1/4x 1-1/4..................
1
8
GW-9935
Shim (between key and gear),
19
GW-20913
Tier Drive Worm Gear (bronze).............
1
1.016 I.D.x 1.468O.D.X.062
Thick............................................
1
REF.
No.
PART
No.
DESCRIPTION
QTY.
* Specify GRADE 5 if ordering part iocaliy.
A/R - As Required
