SINGER W1640 - Manual (Page 11)

REMOVING NEEDLE PLATE
(T
by
Raise
Foot
IjU-
S8t
ffiacbine.
remove
(j presser
Tighten
if.
, presser
fjetween
ition by
I you.
w and
(NOTE: If extension plate is on machine, remove it.)
a) Raise Needle to its highest position by turning hand wheel toward you.
b) Op .1 the hook cover towards you
c) Remove the screws from needle plate. Then remove needle plate.
REMOVING BOBBIN CASE
Raise needle to its highest position by turning hand wheel toward
you. Open Hook Cover.
Lift open hinged latch of bobbin case (Fig. 10) and pull case straight
out of machine (Fig. 11 ).
Bobbin will remain in case as long as latch is open. To remove
bobbin, hold bobbin case down, close latch, and bobbin will fall out
(Fig. 12)
■
le faces
amp as
with a
e corn-
idle is
