Your machine needs lu be oiled once
every week if used rie(|uentJy and
every day if machine is in continual
use. If machine has not been used for
a period ol lime ihe oil will have dried^
so be sure lo oil belore you start
sewing.
Place a drop of best quality sewing
machine oil at each of the points
shown in the pictures:
Inside Face Plaje ^ swing face plate
open and oil all moving parts at
friction points.
UILINU
Under Top Plate ^ remove lop plate by
unscrewing two screws located at each
end of the top plate and oil points
on top of machine head.
Underside - tilt machine head back
and oil points on underside.
It is important that you do not give
the machine too much oil which will
only run out and spot your tabric.
After oiling machine, run Ihe iiiailmie
at high speed so that oil will peiieii.iu-
all moving parts. 'ITien sew a lew low's
of stitches on a scrap rrf material lo
be sure that machine sews cleanly.
Also wipe off any excess oil from lop
of niadiine.
Do not oil the motor as it has been
permanently lubricated at Ihe factory.
4.3
ADJUSTING BELT
JC Penney Model 6105
Serial No.
When ordering replacement parts
give model no and serial no.
The tension of the motor belt can I
adjusted by moving the motor brack
located on the right side of tl
machine.
Use a screwdriver to siighily loosr
the screw securing the molor biacki
Slide bracket down to iighleii icnsh
but be careful not to tighten hr
too tiglitly. Slide bracket up toloosi
tension.
When proper adjustment is attaine
tigliten screw securely.
CATALOG NUMBER-868-2445
MODEL NUMBER 6105
When you need sereice or replacemei
parts, please be sure to give the mod
and serial numbers. They are show
on the model number plate mountc
on the front side of the machine base
