11

THREADING THE BOBBIN CASE

Step 1 illustrated in Fig. 9). Hold bobb;n case between thumb and forefinger of left

hand, so that the slot in the edge of the bobbin case is on top. take the bobbin between

thumb and forefinger of right hand so that the thread on top leads from left to right.

Step 2 Insert bobbin into bobbin case, pull the thread into the slot of the bobbin case as

shown in Fig. 10, and draw it under the tension spring and into the fork-shaped opening

of the spring as shown in Fig. 11.

TENSION SPRING

i

Fig. 10

Fig. 11
