SINGER W311 BBS - Manual (Page 44)

Parts No. Description Pcs Parts No. Description Pcs
123 Stitch plate indicator E , 1 143-S Lamp cord guide set screw 1
124 Stitch plate indicator F
1 144 Lamp cord guide B 1
125 Stitch plate indicator G 1 145 Lamp cord guide pin 1
126 Zigzag width indicator plate 1 146 Lamp complete 1
126— S Zigzag width indicator plate set screw 2 147 Balance wheel 1
127 Zigzag width indicator plate stand 1 148 Clamp stop motion clamp screw 1
128 Zigzag width indicator 1 149 Clamp stop motion washer 1
129 Zigzag width connecting stand washer A 1 150 Clamp stop motion clamp stop screw 1
130 Zigzag width indicator connecting stand washer B 2 151 Spool pin base with spool pin 1
131 Zigzag width connecting stand collar 1 151—S Spool pin base set screw
o
131 — s Zigzag width connecting stand collar set screw 1 152 Felt pad
2
132 Zigzag width connecting arm stud 1 153 Motor set screw 1
132— s Zigzag w'idth connecting arm stud set screw 1 154 Motor set screw washer 1
133 Zigzag width connecting stand 1 BUILT IN MOTOR PARTS
134 Zigzag width connecting arm 1
Parts No. Description Pcs
135 Zigzag width knob 1
135— s Zigzag width knob set screw 2 901 Motor Cover A
1
136 Stitch length knob 1 901-S-A Motor Cover A set screw
1
136— s Stitch length knob set screw 2 901-S-B Motor Cover A set screw 1
137 Lamp installing plate 1 902 Motor Cover B
1
137— s Lamp installing plate set screw 2 902-S-A Motor Cover B set screw
1
138 Lamp cord setter A 1 902-S-B Motor Cover B set screw
1
139 Lamp cord setter B 1 903 Motor belt
1
139— s Lamp cord setter B set screw 1 904 Motor limiting plate
1
140 Bulb 1 904— S Motor limiting plate set screw
2
141 Lamp cord bushing 1 905 Motor bracket 1
142 Lamp cord 1 906 Washer for motor bracket
2
143 Lamp cord guide A 1 907 Nut for motor bracket
2
