SINGER W311 BBS - Manual (Page 43)

Parts No.
Description
Fes
123
Stitch plate indicator E -
1
124
Stitch plate indicator F
1
125
Stitch plate indicator G
1
126
Zigzag width indicator plate
1
126—S
Zigzag width indicator plate set screw
2
127
Zigzag width indicator plate stand
1
128 Zigzag width indicator
1
129
Zigzag width connecting stand washer A
1
130
Zigzag width indicator connecting stand washer
в 2
131
Zigzag width connecting stand collar
1
131-S
Zigzag width connecting stand collar set screw
1
132
Zigzag width connecting arm stud
1
132—S
Zigzag width connecting arm stud set screw
1
133
Zigzag width connecting stand
1
Ш Zigzag width connecting arm
1
135 Zigzag width knob
1
135— S Zigzag width knob set screw
2
136 Stitch length knob
1
136-s Stitch length knob set screw
137 Lamp installing plate
1
137 —S Lamp installing plate set screw
2
138 Lamp cord setter A
1
1.39 Lamp cord setter B
1
139- S Lamp cord setter B set screw
1
140 Bulb
1
141 Lamp cord bushing
1
142 Lamp cord
1
143 Lamp cord guide A
1
I 4J<-
J 43 —s Lamp cord guide set screw
144 Lamp cord guide B
145 Lamp cord guide pin
146 Lamp complete
147 Balance wheel
148 Clamp stop motion clamp screw
149 Clamp stop motion washer
150 Clamp stop motion clamp stop screw
151 Spool pin base with spool pin
151 —s Spool pin base set screw
152 Felt pad
153 Motor set screw
154 Motor set screw washer
BUILT IN MOTOR PARTS
Parts No.
Description
901 Motor Cover A
901-S-A Motor Cover A set screw
901- S-B Motor Cover A set screw
902 Motor Cover В
902- S-A Motor Cover В set screw
902'S-B Motor Cover В set screw
903 Motor belt
904 Motor limiting plate
904—S Motor limiting plate set screw
905 Motor bracket
906 Washer for motor bracket
907 Nut for motor bracket
1
1
1
1
1
1
1
1
1
2
2
1
1
Pcs
1
1
1
1
1
1
1
1
2
1
2
9
