SINGER W2135 User Manual

Page 24

Attention! The text in this document has been recognized automatically. To view the original document, you can use the "Original mode".

background image

22

!

t

Fig. 34

Fig. 35

Avoid over-oiling only a drop is needed at each point.

To oil parts under the bed of the machine, tip the unit back on its hinges and apply a

drop of oil at each point indicated in Fig. 34. -

To oil moving parts inside the face plate, which only rarely require oiling, open plate. Oil

at spots indicated in Fig. 35.
