SINGER W2135 - Manual (Page 10)

---
VLkCmG BOBBIN C.\SE IN SHUTTLE
Open hinged cover plate lefi; oi the needle.
(See 12, Fig. 1) Hold the bobbin case latch, (D),
Fig. 9, between the thumb and forefinger of the left
hand,
with at least three inches of thread running
from the top of the bobbin case to the right. Insert
and center the bobbin case on the stud of the shuttle
body, (C). Be sure
the bobbin case
finger, (E), is op­
posite the shuttle
race notch, (A).
Press the bobbin
case (B) into the
shuttle as far as pos­
sible
until latch
catches on the
center post of the
Fig. 9 shuttle.
THEN release the bobbin case latch, (D).-
Press bobbin case again after latch has been re­
leased to make sure the bobbin case is locked
securely in place. Close the cover plate.
