UPPER THREADING
{Fig. 10)
1) Place spool of thread on upper spool pin,
2) lead thread through arm thread guide A
3) down and around tension discs B from right to
left
4) into the check spring C over threaded discs
5) then pull thread under bar D (See insert, Fig
1 0
)
6) up into take-up lever E from right to left
7) down into thread guide F on face plate
8) through the needle bar thread guide G
Fig. 11
9)
and into needle from left to right. Pull three or four inches of thread through needle
Hold
the
end
of
upper
thread
loosely
and
turn
hand
wheel
toward
you
until
the
needle
goes all the way down and comes back up. A loop (Fig. 11) will be formed over the upper
thread which then can be pulled out straight. Place both thread ends under the slot of the
presser foot and draw toward the back of the machine, leaving both threads three or four
inches long.
