SECTIOK 3. LEAR'vl THE STITCHES

Threading the Machine (3 threads)> Wide/iMarrow Stitch

Using the Needle on the Right Only

(for narrow three-thread serging] 3.5 mm width

Disconnect the machine from the power supply.
Remove the needle and the thread on the left.

Then tighten the needle clamp screw on the left
slightly to avoid losing the screw.

To change to the other needle ¡n three-thread serging

Using the Needle on the Left Only

(for wide three-thread serging) 5.7 mm width

Then tighten the needle clamp screw on the right

slightly to avoid losing the screw.

Loosen both needle clamp screws and remove the needle. Insert the needle to be used and tighten the
needle clamp screw while pushing the needle up as far as it will go. Then tighten the other needle clamp

screw on the other side slightly to prevent the screw from dropping.

Thread Tension (3 threads)

Correct Tension

Adjusting the thread tension may be required

depending on the type of fabric and thread being

used.

Refer to page 25 for the adjustment.
