HOWTO SET UP YOURTRACTOR
CHECK BATTERY
1. Lift hood to raised position.
NOTE: if this battery is put into service
after month and year indicated on labei
(label located between terminals) charge
battery for minimum of one hour at 6-10
amps. (See "BATTERY' in Maintenance
section of this manual for charging
instructions).
2 .
3.
4.
5.
6 .
7.
INSTALLSEAT
Adjust seat before tightening adjustment
knob,
1. Remove adjustment knob and flat
washer securing seat to cardboard
packing and set aside for assembly of
seat to tractor.
Pivot seat upward and remove from
the cardboard packing. Remove the
cardboard packing and discard.
Place seat on seat pan so head of
shoulder bolt is positioned over large
slotted hole in pan.
Push down on seat to engage
shoulder bolt in slot and pull seat
towards rear of tractor.
Pivot seat and pan forward and
assemble adjustment knob and flat
washer loosely. Do not tighten.
Lower seat into operating position and
sit in seat.
Slide seat until a comfortable position
Is reached which allows you to press
clutch/brake p«dal all the way down.
Get off seat without moving its
adjusted position.
Raise seat and tighten adjustment
knob securely.
NOTE: You may now roll or drive your
tractor off the skid. Follow the appropriate
instruction below to remove the tractor
from the skid.
10
