12-1 iSI BAMD SAW/SAWDER, MODEL 113.243300 & 113.243311
FIGURES
SUPPLIED WITH^yODEL 113.243311 ONLY
|Key
i No,
Part No.
Description
1
62614
Leg. . ■
2
60314
t*Screw, Truss Hd. 1/4-20 x 5/8
3
STD54T025
r'Nut, Hex 1/4-20
4
STD551225
t*Lockwasher, 1/4 External
5
68060
Channel, Support :
6
68059
Stiffener, Side
7
.62615
Stiffener, End
S
68061
Support, Motor
9
STD541050
t'Nut, Hex Hd, 1/2-13
10
803835
t Foot, Leveling
69097
“Bag of Loose Parts
HARDWARE FOR MOUNTING TOOL & MOTOR
STD523110
t*Screw, Hex Hd^ 5/16-T8 x 1
STD551131
t 'Lockwasher, Ekt, 5/16
STD541231
t*Nut, Hex Jam 5/16-18
STD551031
t*Washer, 11/32
X
11/16
X
1/16
L_
STD532507
t*Bolt, Carriage 5/16-T8 x 3/4
* Standard Hardware Item — May Be Purchased Locally
t All Parts Contained In Loose Parts Bag
