Dimensions
DIMENSIONS
ft-in.
(mm)
DIM.
UNIT
30GB060
A
13-7%
(4162)
B
11-3
(3429)
C
12-5%
(3797)
D
10
-
0
%
(3061 )
E
5-8%2
(1730)
F
5-3%
(1619)
G
4-6%
(1387)
H
7-6
(2286)
J
5-0
(1524)
COOLER END VIEW
TOP VIEW
SIDE VIEW
'AMER. STD.
ST PIPE THO.
4"-(070 UNIT)
Space for service and airflow.
Mounting weights (approximate) lb
WEIGHT DISTRIBUTION
SUPPORT
UNIT
POINTS
30GB060
1
1578
2
1528
3
922
4
872
10
