542E REQUIRED CLEARANCE (Inches)
Top of unit.................................. 48 Blower access door end______ 30
Duct side of unit......................... 12 End opposite blower
Compressor access door
access end...........................12
side......................................... 30 Bottom of unit above
anticipated snow level.... 6
OUTDOOR FAN
CONTROL ACCESS DOOR
COMPRESSOR
ACCESS DOOR
ELECTRIC HEAT
HIGH-VOLTAGE INLET WITH
MULTIPLE KNOCKOUTS
A79071
542E DIMENSIONS (Inches)
Size
A
B
c
D
E
F
G
H
J
024 & 030
60-3/16
32-3/16
24-13/16
21
11-1/2
13-5/16
57
6-7/8
6-15/16
036
60-3/16
32-3/16
24-13/16
21
13-3/4
13-5/16
57
4-5/8
6-15/16
042, 048, & 060
68-3/16
40-3/16
30-13/16
21
16-3/8
17-5/16
65
5-1/8
7-1/2
Sizes
K
L
M
N
P
R
S
T
TJ
V
024 & 030
18-1/8
1-1/2
15-3/32
12-9/16
14-1/2
28-9/16
37-1/8
2
7/8
27-7/8
036
18-1/8
1-1/2
15-3/32
12-9/16
14-1/2
28-9/16
37-1/8
2
7/8
27-7/8
042, 048, & 060
25
1-1/2
20-3/32
15-1/8
18-1/2
34-9/16
44-1/4
2
7/8
35-3/16
Figure 3—542E Dimensional Drawing
TABLE l-RATiNGS, PERFORMANCE, & RECOMMENDED FILTER SIZES
MODEL
542E
5420
SIZE
024
030
036
042
048
060
060
SERIES
A
A
A
A
A
A
A
Rated Heating Capacity @ 47°F (Btuh)*
**
26,000
30,000
35,000
42,000
48,000
58,000
58,00011
Total Power Consumption (Watts)*
2850
3450
3850
4600
5100
6300
6300tt
COP*
2.7
2.5
2.7
2.7
2.8
2.7
2.7t-
Rated Heating Capacity® 17°F (Btuh)*
13,500
16,000
18,000
21,000
25,000
31,000
31,00011
Total Power Consumption (Watts)*
2350
2900
3000
3700
4150
5300
530011
COP*
1.7
1.6
1.8
1.7
1.8
1.7
1.711
Rated Cooling Capacity @ 95°F (Btuh)*
25,500
30,000
35,000
41,000
47,000
57,000
57,00011
Total Power Consumption (Watts)*
3350
3900
4650
5150
6100
7600
7600-t
EER
7.6
7.7
7.5
8.0
7.7
7.5
7.511
Rated Indoor Airflow (Ft^/Min)*
850
1050
1300
1535
1700
2000
200011
Rated External Statio Pressure (In. wc)*
0.10
0.15
0.15
0.15
0.20
0.20
0.2011
ARI Sound Rating Humbert
19
19
19
18
18
20
20
Recommended Minimum Filter Size (Sq ln.)t
Standard-Type
408
504
624
737
816
960
**
Cleanable-or High-Capacity-Type
265
328
406
479
530
624
**
* Rated in accordance with ARI Standard 240-77.
t Rated in accordance with ARI Standard 270-75.
f Recommended field-supplied filter sizes shown are based on a velocity of 300 ft/min at the rated indoor airflow.
**Two 20
X
20
X
1 air filters are furnished with Model 542D060.
ttTo achieve the performance ratings indicated, the fresh-air and exhaust openings of the plenum section must be sealed airtight, the
fresh-air damper must be insulated, and the plenum section must be supported by a curb around an opening to the indoor airspace.
-
