79
Port: Front Firing
Frequency Response: 20-30/150Hz Adjustable
Low Pass Filter: Level adjustable, switchable in/out; 12dB/octave or 18dB/octave
High Pass Filter: Switchable in/out; 6dB/out; or 12dB/octave
Phase: Continuously variable from 0-180 degrees
EQ: Switchable in/out, +10dB boost to -10dB cut; variable Q from .2 to 2; variable fre-
quency selector from 30 to 150Hz
Finish: Standard Wilsongloss finishes, Custom finishes available at additional cost
Amplifier:
Power: 400 Watts
Input Impedance: 56 K ohms single ended, 4 K ohms balanced
Inputs: Balanced and single ended for Right, Left and Processor/LFE
Outputs: Balanced and single ended for Right, Left, High Pass filter outputs
Drive Unit: 12 inch long throw
Height: 27
1/2
inches
Width: 18 inches
Depth: 27
1/2
inches (add 3
1/2
inches for grill & heat sink)
Approx. Product Weight: 283 lbs
S p e c i f i c a t i o n s
