Wilkerson V08 - Manual

INSTALLATION
1. Refer to WARNING prior to installation.
2. Install as close to the point of use as possible.
3. Unit must be installed with the flow in the direction of the flow arrow on
face of shut off blade.
4. Avoid using reducing bushings, couplings, etc., whenever possible to
install this product. These devices restrict air flow and can affect
performance.
5. Maximum pressure rating is 150 psig (10.3 bar). Temperature range is
32°F to 150°F (0°C to 65.5°C).
6. Unit can be locked in the closed position using a standard padlock.
MAINTENANCE
THE UNIT MUST BE REMOVED FROM THE COMPRESSED AIR LINE.
1. Remove retaining screws, and separate body halves.
2. Remove shut off blade.
3. Remove O-rings from body halves.
4. Lightly lubricate O-rings and place in grooves on body halves.
5. Align shut off blade on pivot pin located on outlet body half as shown.
6. Place body halves together and tighten screws to approximately 20 in/lbs.
Installation & Service Instructions
84-021-000
Safety Lockout Valve Model V08
ISSUED: March, 2005
Supersedes: April, 2002
Doc. #84-021-000, Rev. 2
Richland, MI 49083 Tel: (269) 629-5000
WARNING
To avoid unpredictable system behavior that can cause personal injury
and property damage:
• Disconnect electrical supply (when necessary) before installation,
servicing, or conversion.
• Disconnect air supply and depressurize all air lines connected to
this product before installation, servicing, or conversion.
• Operate within the manufacturer’s specified pressure, temperature,
and other conditions listed in these instructions.
• Medium must be moisture-free if ambient temperature is below
freezing.
• Service according to procedures listed in these instructions.
• Installation, service, and conversion of these products must be
performed by knowledgeable personnel who understand how
pneumatic products are to be applied.
• After installation, servicing, or conversion, air and electrical supplies
(when necessary) should be connected and the product tested for
proper function and leakage. If audible leakage is present, or the
product does not operate properly, do not put into use.
• Warnings and specifications on the product should not be covered
by paint, etc. If masking is not possible, contact your local
representative for replacement labels.
!
WARNING
FAILURE OR IMPROPER SELECTION OR IMPROPER USE OF THE
PRODUCTS AND/OR SYSTEMS DESCRIBED HEREIN OR RELATED
ITEMS CAN CAUSE DEATH, PERSONAL INJURY AND PROPERTY
DAMAGE.
