Wilkerson SB2 - Manual

Installation & Service Instructions
83-949-000
SB1 & SB2
Filter / Regulator Series
ISSUED: May , 2008
Supersedes: August , 2006
Doc.# 83949000, EN# 080328, Rev. 5
Introduction
Follow these instructions when installing, operating, or servicing the product.
Application Limits
These products are intended for use in general purpose compressed air systems
only.
Maximum Recommended Pressure Drop:
kPa PSIG bar
Particulate Filter 70 10 0.7
Operating Pressure Maximum kPa PSIG bar
Bowl w/ Twist Drain / No Sight Gauge 2068 300 21.0
Bowl w/ Autodrain / No Sight Gauge 1210 175 12.1
Bowl w/ Twist Drain and Sight Gauge 1700 250 17.0
Bowl w/ Autodrain and Sight Gauge 1210 175 12.1
Operating Temperature Range:
SB1-02-LYSO
0°F to 150°F (-18°C to 66°C)
SB1-02-LYSS 0°F to 180°F (-18°C to 82°C)
Auto Pulse Drain 32°F to 150°F (0°C to 66°C)
SB2-04-LLS0, with or without Sight Gauge 0°F to 150°F (-18°C to 66°C)
SB2-04-LLSS, without Sight Gauge 0°F to 180°F (-18°C to 82°C)
SB2-04-LLSS, with Sight Gauge 0°F to 150°F (-18°C to 66°C)
Automatic Float Drain 32°F to 150°F (0°C to 66°C)
Standard Size Low Temperature Operating Temperature: -40°C/F
Note: Air must be dry enough to avoid ice formation at temperatures
below 32°F (0°C).
Symbols
Filter / Regulator
Installation
1. The Filter / Regulator should be installed with reasonable accessibility for
service whenever possible – repair service kits are available. Keep pipe or
tubing lengths to a minimum with inside clean and free of dirt and chips.
Pipe joint compound should be used sparingly and applied only to the male
pipe – never into the female port. Do not use PTFE tape to seal pipe joints
– pieces have a tendency to break off and lodge inside the unit, possibly
causing malfunction. Also, new pipe or hose should be installed between
the Filter / Regulator and equipment being protected.
2. The upstream pipe work must be clear of accumulated dirt and liquids.
3. Select a Filter / Regulator location as close as possible to the equipment
being protected.
4. Install Filter / Regulator so that air flows in the direction of arrow on body.
5. Install Filter / Regulator vertically with the bowl drain mechanism at the
bottom. Free moisture will thus drain into the sump (“quiet zone”) at the
bottom of the bowl.
6. Gauge ports are located on both sides of the Filter / Regulator body for your
convenience. It is necessary to install a gauge or socket pipe plugs into each
port during installation.
Operation
1. Both free moisture and solids are removed automatically by the filter.
2. Manual drain filters must be drained regularly before the separated moisture
and oil reaches the bottom of the baffle or end cap.
3. The filter element should be removed and replaced when pressure
differential across the filter is 69 kPa (10 PSIG).
4. Before turning on the air supply:
4A. On SB1, disengage the adjusting knob by pulling upward. Turn adjusting
knob counterclockwise until the compression is released from the pressure
control spring.
4B. On SB2, push down on the adjusting knob while turning knob
counterclockwise until the compression is released from the pressure control
spring. (Knob is locked when up.)
5. Then turn knob clockwise and adjust regulator to desired downstream
pressure. This permits pressure to build up slowly in the downstream line.
6. To decrease regulated pressure settings, always reset from a pressure lower
than the final setting required. Example, lowering the secondary pressure
from 550 to 410 kPa (80 to 60 PSIG) is best accomplished by dropping the
secondary pressure to 350 kPa (50 PSIG), then adjusting upward to 410
kPa (60 PSIG).
7. When desired secondary pressure settings have been reached, push the
knob down to lock this pressure setting on the SB1 or up to lock on the
SB2.
Richland, MI 49083 Tel: (269) 629-5000
WARNING
To avoid unpredictable system behavior that can cause personal injury
and property damage:
• Disconnect electrical supply (when necessary) before installation,
servicing, or conversion.
• Disconnect air supply and depressurize all air lines connected to this
product before installation, servicing, or conversion.
• Operate within the manufacturer’s specified pressure, temperature,
and other conditions listed in these instructions.
• Medium must be moisture-free if ambient temperature is below
freezing.
• Service according to procedures listed in these instructions.
• Installation, service, and conversion of these products must be
performed by knowledgeable personnel who understand how
pneumatic products are to be applied.
• After installation, servicing, or conversion, air and electrical supplies
(when necessary) should be connected and the product tested for
proper function and leakage. If audible leakage is present, or the
product does not operate properly, do not put into use.
• Warnings and specifications on the product should not be covered by
paint, etc. If masking is not possible, contact your local representative
for replacement labels.
!
WARNING
FAILURE OR IMPROPER SELECTION OR IMPROPER USE OF THE
PRODUCTS AND/OR SYSTEMS DESCRIBED HEREIN OR RELATED ITEMS
CAN CAUSE DEATH, PERSONAL INJURY AND PROPERTY DAMAGE.
This document and other information from The Company, its subsidiaries
and authorized distributors provide product and/or system options for further
investigation by users having technical expertise. It is important that you
analyze all aspects of your application, including consequences of any failure
and review the information concerning the product or systems in the current
product catalog. Due to the variety of operating conditions and applications for
these products or systems, the user, through its own analysis and testing, is
solely responsible for making the final selection of the products and systems
and assuring that all performance, safety and warning requirements of the
application are met.
The products described herein, including without limitation, product features,
specifications, designs, availability and pricing, are subject to change by The
Company and its subsidiaries at any time without notice.
EXTRA COPIES OF THESE INSTRUCTIONS ARE AVAILABLE FOR INCLUSION
IN EQUIPMENT / MAINTENANCE MANUALS THAT UTILIZE THESE PRODUCTS.
CONTACT YOUR LOCAL REPRESENTATIVE.
!
WARNING
Product rupture can cause serious injury.
Do not connect regulator to bottled gas.
Do not exceed maximum primary pressure rating.
!
Safety Guide
For more complete information on recommended application guidelines, see
the Safety Guide section of Pneumatic Division catalogs or you can download
the
Pneumatic Division Safety Guide at: www.wilkersoncorp.com
