Gas inlet temperatures
Type
PC 510 NT
PC 511 NT
PC 520 NT
PC 610 NT
PC 611 NT
PC 620 NT
Inlet
hose nozzle for tubing I.D. 3/8“
(hose nozzle DN 10 mm)
Outlet
hose nozzle for tubing I.D. 3/8“
(hose nozzle DN 10 mm)
Coolant connection
(waste vapor condenser)
hose nozzle for tubing
I.D. 1/4” - 5/16”
(hose nozzle DN 6-8 mm)
Maximum permissible pressure
of coolant at waste vapor con-
denser
psi
(bar)
87 (absolute)
(6 (absolute))
Permissible range of coolant
temperature (waste vapor con-
denser)
°F
(°C)
5 to 68
(-15 to +20)
Volume of catchpot
(only pumping unit)
qt
(ml)
0.52
(500)
A-weighted emission sound
pressure level**
(uncertainty K
pA
: 3 dB(A))
dB(A) 45
Dimensions L x W x H approx.
PC 510 NT / PC 610 NT
PC 511 NT / PC 611 NT
PC 520 NT / PC 620 NT
in (mm)
in (mm)
in (mm)
16.5 x 9.6 x 17.5 (419 x 243 x 444)
17.1 x 9.6 x 17.5 (435 x 243 x 444)
17.1 x 14.2 x 17.5 (435 x 361 x 444)
Weight approx.
PC 510 NT / PC 610 NT
PC 511 NT / PC 611 NT
PC 520 NT / PC 620 NT
lbs. (kg)
lbs. (kg)
lbs. (kg)
36.8 (16.7)
37.3 (16.9)
39.0 (17.7)
43.9 (19.9)
44.3 (20.1)
46.1 (20.9)
* Pumping speed of diaphragm pump
** Measurement according to EN ISO 2151:2004 and EN ISO 3744:1995 at 230V/50Hz and ulti-
mate vacuum with exhaust tube at outlet.
* if pumping potentially explosive atmospheres: 50 °F to 104 °F (+10°C to +40°C)
Operating condition Inlet pressure
Permitted range of gas
temperatures at inlet
Continuous operation
> 75 Torr (100 mbar)
(high gas load)
➨
50 °F to 104 °F
(+10°C to +40°C)
Continuous operation
< 75 Torr (100 mbar)
(low gas load)
➨
32 °F to 140 °F*
(0°C to +60°C*)
Short-time
(< 5 minutes)
< 75 Torr (100 mbar)
(low gas load)
➨
14 °F to 176 °F*
(-10°C to +80°C*)
