Table 5A — Accessory Electric Heater Data (60 Hz)
UNIT
40RMQ
HEATER
PART NO.
V-PH-Hz
NOMINAL kW
HEATER
AMPS
MCA*
MOCP*
008
CAELHEAT001A00
240-3-60
5
12.0
25.6
30
CAELHEAT002A00
480-3-60
6.0
12.3
15
CAELHEAT003A00
575-3-60
5.0
11.9
15
CAELHEAT004A00
240-3-60
10
24.1
40.7
50
CAELHEAT005A00
480-3-60
12.0
19.8
25
CAELHEAT006A00
575-3-60
10.0
18.1
25
CAELHEAT007A00
240-3-60
15
36.0
55.7
80
CAELHEAT008A00
480-3-60
18.0
27.4
40
CAELHEAT009A00
575-3-60
15.1
24.4
35
CAELHEAT010A00
240-3-60
25
60.1
85.8
125
CAELHEAT011A00
480-3-60
30.1
42.4
60
CAELHEAT012A00
575-3-60
25.1
67.0
50
CAELHEAT013A00
240-3-60
35
84.0
115.8
175
CAELHEAT014A00
480-3-60
42.1
57.4
80
CAELHEAT015A00
575-3-60
35.1
49.5
70
LEGEND
MCA
— Minimum Circuit Amps
MOCP — Maximum Overcurrent Protection (Amps)
*Sizes shown are for single-point connection of electric heat acces-
sory and air handler.
NOTES:
1. MCA and MOCP values apply to both standard and alternate factory-
supplied motors.
2. Electrical resistance heaters are rated at 240 v, 480 v, or 575 v. To
determine heater capacity (kW) at unit nameplate voltage, multi-
ply 240-v, 480-v, or 575-v capacity by multipliers found in table
below.
HEATER RATING
VOLTAGE
ACTUAL HEATER VOLTAGE
200
208
230
240
400
440
460
480
550
575
600
240
.694
.751
.918
1
—
—
—
—
—
—
—
480
—
—
—
—
.694
.840
.918
1
—
—
—
575
—
—
—
—
—
—
—
—
.915
1
1.089
NOTE: The following equation converts kW of heat energy to Btuh:
kW x 3.412 = Btuh.
Table 5B — Accessory Electric Heater Data (50 Hz)
UNIT
40RMQ
HEATER
PART NO.
V-PH-Hz
NOMINAL kW
HEATER
AMPS
MCA*
MOCP*
008
CAELHEAT002A00
400-3-50
3.47
5.0
11.1
15
CAELHEAT001A00
230-3-50
4.59
11.5
25.0
30
CAELHEAT005A00
400-3-50
6.94
10.0
17.3
25
CAELHEAT004A00
230-3-50
9.18
23.1
39.5
50
CAELHEAT008A00
400-3-50
10.42
15.0
23.6
30
CAELHEAT007A00
230-3-50
13.78
34.6
53.9
80
CAELHEAT011A00
400-3-50
17.36
25.1
36.2
50
CAELHEAT010A00
230-3-50
22.96
57.6
82.6
110
CAELHEAT014A00
400-3-50
24.31
35.1
48.7
70
CAELHEAT013A00
230-3-50
32.14
80.7
111.5
175
CAELHEAT017A00
400-3-50
6.94
10.0
23.0
30
CAELHEAT016A00
230-3-50
9.18
23.1
39.5
50
CAELHEAT020A00
400-3-50
13.89
20.0
35.5
50
CAELHEAT019A00
230-3-50
18.37
46.1
79.9
110
CAELHEAT023A00
400-3-50
20.83
30.1
48.1
70
CAELHEAT022A00
230-3-50
27.55
69.2
108.7
150
LEGEND
MCA
— Minimum Circuit Amps
MOCP — Maximum Overcurrent Protection (Amps)
*Sizes shown are for single-point connection of electric heat acces-
sory and air handler.
NOTES:
1. MCA and MOCP values apply to both standard and alternate factory-
supplied motors.
2. Electrical resistance heaters are rated at 230 v or 400 v. To de-
termine heater capacity (kW) at unit nameplate voltage, multiply
230-v or 400-v capacity by multipliers found in table below.
HEATER RATING
VOLTAGE
ACTUAL HEATER VOLTAGE
220
230
240
380
400
415
230
.915
1.0
1.084
—
—
—
400
—
—
—
0.903
1.0
1.076
898
