Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Network Configuration Menu
4-14
Cisco Unified IP Phone 7931G Administration Guide for Cisco Unified Communications Manager 6.1
OL-14587-01
SW Port
Configuration
Speed and duplex of the network port
(labeled 10/100 SW). Valid values:
•
Auto Negotiate
•
10 Half—10-BaseT/half duplex
•
10 Full—10-BaseT/full duplex
•
100 Half—100-BaseT/half duplex
•
100 Full—100-BaseT/full duplex
If the phone is connected to a switch,
configure the port on the switch to the
same speed/duplex as the phone, or
configure both to auto-negotiate.
If you change the setting of this option,
you must change the PC Port
Configuration option to the same setting.
1.
Unlock network configuration
options.
2.
Scroll to the SW Port Configuration
option and then press the Edit
softkey.
3.
Scroll to the setting that you want
and then press the Select softkey.
4.
Press the Save softkey.
PC Port
Configuration
Speed and duplex of the access port
(labeled 10/100 PC). Valid values:
•
Auto Negotiate
•
10 Half—10-BaseT/half duplex
•
10 Full—10-BaseT/full duplex
•
100 Half—100-BaseT/half duplex
•
100 Full—100-BaseT/full duplex
If the phone is connected to a switch,
configure the port on the switch to the
same speed/duplex as the phone, or
configure both to auto-negotiate.
If you change the setting of this option,
you must change the SW Port
Configuration option to the same setting.
1.
Unlock network configuration
options.
2.
Scroll to the PC Port Configuration
option and then press the Edit
softkey.
3.
Scroll to the setting that you want
and then press the Select softkey.
4.
Press the Save softkey.
Table 4-2
Network Configuration Menu Options (continued)
Option
Description
To Change
