C-CV854D-3 (CE)
For camera: 24 V AC, 50/60 Hz, or 12 V DC
For Heater: 24 V AC, 50/60 Hz
4 W (300 mA, maximum current: 800 mA)
1/3 type IT-CCD
752 (H) x 582 (V), 440,000 pixels
2:1 interlace
Horizontal: 15.625 kHz, Vertical: 50 Hz
VBS1.0 V(p-p), 75 Ω, RCA pin jack
VBS1.0 V(p-p), 75 Ω, BNC-R jack
Internal synchronization
Horizontal: 500 lines , Vertical: 410 lines
50 dB
0.5 lx (350 mV, color operation), 0.1 lx (140 mV, color operation),
0.05 lx (350 mV, black and white operation, incandescent lamp)
Color-to-B/W mode: Approx. 5 lx
B/W-to-color mode: Approx. 25 lx (incandescent lamp)
ATW/AWB (switch selector)
f=3.0 mm – 9.0 mm
1:1.4 – 2.4
Auto-iris
Horizontal: 90.3º– 31.9º, Vertical: 66.4º– 23.9º
ON/OFF (used for focus adjustment)
Automatic/Off (switch selector)
Backlight compensation, Shutter speed, Iris control,
Max. 4 x sensitivity increase (auto), Noise reduction
IP66
– 10ºC to + 50ºC (14°F to 122°F)
(When an optional heater unit is attached: – 30ºC to + 50ºC (– 22°F to 122°F))
90% RH or less (no condensation)
Outdoor/Indoor use
Case, bezel : Die-cast Aluminum, light gray, paint Dome cover : PC resin
(transparent)
ø154.2 x 110 (H) mm (ø6.07 x 4.33 (H) inch) (excluding the cables)
1.1 kg (2.43 lb)
Model No.
Power Source
Power Consumption
Image Device
Number of Effective Pixels
Scanning System
Scanning Frequency
Monitor Output
Video Output
Synchronizing System
Resolution (at center)
S/N Ratio
Minimum Illumination
(Flickerless: OFF)
Threshold illumination
for mode switching
White Balance Mode
Focal Length
Maximum Aperture Ratio
Iris
Angle of View
Adjustment Switch
Day/Night Mode
Other Functions
Water/Dust Protection
Operating Temperature
Operating Humidity
Applications
Finish
Dimensions
Weight
The design and specifications are subject to change without notice for improvement.
Note
No camera mounting screws are supplied. For mounting, use screws of 4 x 25 mm (0.16" x 0.98") or longer.
• Accessories
L-type wrench ............................................. 1
Base gasket ............................................... 1
• Optional products
Heater unit: C-A854H
Flush ceiling mounting bracket: C-BC850U
Wall mounting bracket: C-BC850W
