15
C-CV854D-3 (CU) C-CV854D-9 (CU)
For camera: 24 V AC, 50/60 Hz or 12 V DC
For Heater: 24 V AC, 50/60 Hz
4 W (300 mA, maximum current: 800 mA)
1/3 type IT-CCD
768 (H) x 494 (V), 380,000 pixels
2:1 interlace
Horizontal: 15.734 kHz , Vertical: 59.94 Hz
VBS1.0 V(p-p), 75 Ω, RCA pin jack
VBS1.0 V(p-p), 75 Ω, BNC-R jack
Internal synchronization
Horizontal: 540 lines, Horizontal: 480 lines,
Vertical: 350 lines Vertical: 350 lines
50 dB
0.5 lx (50 IRE, color operation), 0.1 lx (20 IRE, color operation),
0.05 lx (50 IRE, black and white operation, incandescent lamp)
Color-to-B/W mode: Approx. 5 lx
B/W-to-color mode: Approx. 25 lx (incandescent lamp)
ATW/AWB (switch selector)
f=3.0 mm – 9.0 mm f=9.0 mm – 22.0 mm
1:1.4 – 2.4 1:1.5 – 2.9
Auto-iris
Horizontal: 90.3º– 31.9º, Horizontal: 30.6º– 13.0º,
Vertical: 66.4º– 23.9º Vertical: 22.6º– 9.8º
ON/OFF (used for focus adjustment)
Automatic/Off (switch selector)
Backlight compensation, Shutter speed, Iris control,
Max. 4 x sensitivity increase (auto), Noise reduction
IP66
– 10ºC to + 50ºC (14°F to 122°F)
(When an optional heater unit is attached: – 30ºC to + 50ºC (– 22°F to 122°F))
90% RH or less (no condensation)
Outdoor/Indoor use
Case, bezel : Die-cast Aluminum, light gray, paint, Dome cover : PC resin
(transparent)
ø154.2 x 110 (H) mm (ø6.07 x 4.33 (H) inch) (excluding the cables)
1.1 kg (2.43 lb)
Model No.
Power Source
Power Consumption
Image Device
Number of Effective Pixels
Scanning System
Scanning Frequency
Monitor Output
Video Output
Synchronizing System
Resolution (at center)
S/N Ratio
Minimum Illumination
(Flickerless: OFF)
Threshold illumination
for mode switching
White Balance Mode
Focal Length
Maximum Aperture Ratio
Iris
Angle of View
Adjustment Switch
Day/Night Mode
Other Functions
Water/Dust Protection
Operating Temperature
Operating Humidity
Applications
Finish
Dimensions
Weight
10. SPECIFICATIONS
The design and specifications are subject to change without notice for improvement.
Note
No camera mounting screws are supplied. For mounting, use screws of 4 x 25 mm (0.16" x 0.98") or longer.
