Toa HX-7W-WP - Manual (Page 16)

16
• Filter characteristics when used with the FB-150 series Subwoofer System
Note
When using the processor with the HX-7 Series and the FB-150 Series, ensure that the wiring polarity of both
units is the same.
[When using the 0º mode]
Filter Frequency Gain Q Delay
HX-7 Series
HPF (12 dB) 90 Hz - 0.700
0 ms
PEQ 160 Hz 3.0 1.011
PEQ 1.75 kHz -3.5 3.633
PEQ 4.62 kHz -7.0 2.145
PEQ 9.25 kHz -7.5 1.414
FB-150 Series
HPF (12 dB) 30 Hz - 1.000
0 ms PEQ 40 Hz 3.0 1.414
LPF (12 dB) 100 Hz - 1.000
[When using the 15º mode]
Filter Frequency Gain Q Delay
HX-7 Series
HPF (12 dB) 90 Hz - 0.700
0 ms
PEQ 160 Hz 3.0 1.011
PEQ 1.75 kHz -3.0 3.633
PEQ 4.62 kHz -7.5 2.145
FB-150 Series
HPF (12 dB) 30 Hz - 1.000
0 ms PEQ 40 Hz 3.0 1.414
LPF (12 dB) 100 Hz - 1.000
[When using the 30º mode]
Filter Frequency Gain Q Delay
HX-7 Series
HPF (12 dB) 90 Hz - 0.700
0 ms
PEQ 160 Hz 3.0 1.011
PEQ 1.75 kHz -2.0 3.633
PEQ 5.00 kHz -3.5 1.414
FB-150 Series
HPF (12 dB) 30 Hz - 1.000
0 ms PEQ 40 Hz 3.0 1.414
LPF (12 dB) 100 Hz - 1.000
[When using the 45º mode]
Filter Frequency Gain Q Delay
HX-7 Series
HPF (12 dB) 90 Hz - 0.700
0 ms
PEQ 160 Hz 3.0 1.011
PEQ 1.75 kHz -2.5 3.633
PEQ 4.62 kHz -2.5 2.456
FB-150 Series
HPF (12 dB) 30 Hz - 1.000
0 ms PEQ 40 Hz 3.0 1.414
LPF (12 dB) 100 Hz - 1.000
[When using the 60º mode]
Filter Frequency Gain Q Delay
HX-7 Series
HPF (12 dB) 90 Hz - 0.700
0 ms PEQ 160 Hz 3.0 1.011
PEQ 5.30 kHz -3.0 2.456
FB-150 Series
HPF (12 dB) 30 Hz - 1.000
0 ms PEQ 40 Hz 3.0 1.414
LPF (12 dB) 100 Hz - 1.000
