16. SPECIFICATIONS
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
Suspension bracket .................................... 2
Hex head wrench ....................................... 1
Model No. HX-5B HX-5W HX-5B-WP HX-5W-WP
Enclosure Bass-reflex type Sealed type
Power Handling Capacity Continuous pink noise: 200 W, Continuous program: 600 W
Rated Impedance 8 Ω
Sensitivity (1 W, 1m) 96 dB (60° mode), 97 dB (45° mode), 98 dB (30° mode), 99 dB (15° mode)
Frequency Response 70 to 20,000 Hz (60° mode) 95 to 20,000 Hz (60° mode)
(Deviation –10 dB) 75 to 20,000 Hz (45° mode) 100 to 20,000 Hz (45° mode)
80 to 20,000 Hz (30° mode) 105 to 20,000 Hz (30° mode)
85 to 20,000 Hz (15° mode) 110 to 20,000 Hz (15° mode)
Crossover Frequency 4 kHz
Directivity Angle Horizontal: 100° (over 2,000 Hz)
Vertical:
60° (over 800 Hz), 45° (over 1.2 kHz), 30° (over 1.6 kHz),
15° (over 3.2 kHz) variable
Speaker Component Low frequency: 12 cm (5") cone-type x 4
High frequency: Balanced dome-type x 12
Input Terminal Speakon NL4MP x 2 and M4 screw terminal –
Speaker Cord – 2-core cabtyre cord with diameter of 6 mm
or
15/64 in. (60 cm or 23 5/8 in. long)
Water Protection – IPX4*
Operating Temperature – –15°C to +50°C
Finish (Enclosure) Polypropylene, black Polypropylene, white Polypropylene, black Polypropylene, white
Dimensions 408 (w) x 546 (h) x 342 (d) mm
16 1/16 (w) x 21 1/2 (h) x 13 15/32 (d) inches
Weight 16 kg
* Install with the every speaker module downward.
15. EQUALIZATION USING A DIGITAL SIGNAL PROCESSOR
The speaker systems are to reproduce wide-band, high-efficiency sound even without the use of an equalizer.
However, sound quality can be made even clearer and more dynamic with the addition of a TOA digital signal
processor set as shown in the table.
[Filter characteristics for normal mode]
[Filter characteristics for low-frequency cut mode (speech applications) or when used with the FB-120
series Subwoofer System]
Filter Frequency Gain Q
HPF BW (24 dB/oct) 90 Hz – –
PEQ 800 Hz –3 dB 0.7
2.5 kHz –4 dB 2.997
5 kHz +5 dB 0.305
Filter Frequency Gain Q
HPF (12 dB/oct) 60 Hz – 2.053
PEQ 65 Hz +2 dB 1.414
800 Hz –3 dB 0.7
2.5 kHz –4 dB 2.997
5 kHz +5 dB 0.305
Note
When using the processor with the HX-5
series and the FB-120 series, ensure
that the wiring polarity of both units is the
same.
533-06-125-5B
