Traceability Information for Europe (EMC directive 2004/108/EC)
Manufacturer:
TOA Corporation
7-2-1, Minatojima Nakamachi, Chuo-ku, Kobe, Hyogo,
Japan
Authorized representative:
TOA Electronics Europe GmbH
Suederstrasse 282, 20537 Hamburg,
Germany
[Voice Announcement Board EV-200M]
24 V DC, 0.1 A
3 W
0 dB*
20 – 20,000 Hz (44.1 kHz sampling, 1 kHz reference)
20 – 14,000 Hz (32 kHz sampling, 1 kHz reference)
Under 0.3% (44.1 kHz, recording method: Extremely High)
CF card (supplied)
Number of mountable card: 1
Single source playback
8 programs
0 – 50°C
Under 90% (no dew condensation)
120 (w) x 18.6 (h) x 121 (d) mm
110 g
Power Source
Power Consumption
Output
Frequency Response
Distortion
Memory Card
Playback Mode
No. of Playback Program
Operating Temperature
Operating Humidity
Dimensions
Weight
Mounting screw ........................................ 2
CF card .................................................... 1
* 0 dB = 1 V
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
[Surveillance Board SV-200MA]
24 V DC
120 mA
Input:
No-voltage make contact input, open voltage: 3.3 V DC,
sort-circuit current: under 1 mA
(1) Speaker line initial setting activation signal
(2) Speaker line surveillance activation signal
Output: Open collector output, withstand voltage: 30 V DC,
control current: under 10 mA
(1) Monitoring short or open of individual speaker line (zone 1 – 5)
(2) Ground fault (insulation resistance: under 50 kΩ)
(3) Power amplifier failures
Input/Output
Input:
No-voltage make contact input, open voltage: 24 V DC,
sort-circuit current: under 60 mA
Output: Open collector output, withstand voltage: 24 V DC (used with VM
24 V DC output), control current: under 20 mA
(1) Speaker Zone information/selection
(2) Power amplifier fault link
Connector: D-sub connector (25-pin, female)
Power amplifier failure: 20 kHz pilot tone detection
Speaker line failure:
40 Hz impedance detection
Speaker lines are automatically monitored at set time intervals .
(10 – 60 min, at 10 min intervals)
0 – 50°C
Under 90% RH (no dew condensation)
90 (w) x 20.6 (h) x 157 (d) mm
140 g
Power Source
Current Consumption
Control Input and Output
Failure Detection
Speaker Line Surveillance
Set Time
Operating Temperature
Operating Humidity
Dimensions
Weight
Flat cable ................................................. 2
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
