[Dimensional diagram for printing devices]

Name label A

Cutting size: 30 x 110 mm

Name label B

Cutting size: 30 x 136 mm

30

30

26

26

13

13

7

9 x 13 (=117)

136

13

13

7

110

POWER

FAULT

EMERGENCY

ACTIVATION

GROUP 1

GROUP 2

ALL-ZONE

ZONE 2

ZONE 3

ZONE 4

ZONE 5

MESSAGE 1

MESSAGE 2

MESSAGE 3

MESSAGE 4

MESSAGE 5

ZONE 1

Names are assigned as an example.
Unit: mm
