Page 59: Accessories

background image

59

[Remote Microphone Extension RM-210]

20 mA maximum (in terms of RM-200M's DC power input)
Connection to RM-200M by dedicated cable
Activation of Voice Announcement Board's voice messages when
controlling speakers in 10 zones at RM-200M
ABS resin
110 (w) x 76.5 (h) x 215 (d) mm
350 g

Current Consumption
Connection
Function

Finish
Dimensions
Weight

24 V DC (Operating range: 14 – 28 V DC)
Power input jack:

Non-polarity type

Usable power input plug*

3

: Outer diameter ø5.5 mm, inner diameter

ø2.1 mm, length 9.5 mm

100 mA maximum
Under 1%
100 – 20,000 Hz
Over 60 dB
0 dB*

1

, 600 Ω, balanced

Unidirectional electret condenser microphone
Zones 1 – 5 or Zones 1 – 10 (2 stacked amplifiers connection),
Groups 1 – 2, and All-Zone Broadcast
Activation of Emergency Broadcast (pre-recorded announcement*

2

or live microphone announcement) by Emergency Broadcast Switch
Activation of 5 messages*

2

Up to 4
RS-485 Control
Microphone volume control
Category 5 STP cable, RJ45 connector
800 m maximum in total
Only a single unit can be power-supplied from VM-2120 or VM-
2240 amplifier. Line resistance: Under 40 Ω (one way)
ABS resin
190 (w) x 76.5 (h) x 215 (d) mm (Gooseneck microphone excluded)
750 g

Power Source

Current Consumption
Distortion
Frequency Response
Signal-to-Noise Ratio
Audio Output
Microphone
Speaker Control

Emergency Broadcast

Voice Message Control
No. of Connectable Units
Communication System
Volume Control
Connection Cable and Connector
Communication Distance
DC Power Supply from Amplifier

Finish
Dimensions
Weight

[Remote Microphone RM-200M]

Remarks

120 V AC version

230 V AC version

Part name

AD-4800 (US)
AD-4800 (ER)
AD-4800 (BS)
AD-4800 (AS)

Part code

100-07-290-70
100-07-291-80
100-07-292-10
100-07-293-60

*

1

0 dB = 1 V

*

2

An optional EV-200M Board must be mounted in the VM-2120 or VM-2240 Amplifier.
The voice messages must be pre-recorded into a CF (CompactFlash) card to be inserted into the EV-200M
Board.

*

3

Suppliable AC adapters

Note: The design and specifications are subject to change without notice for improvement.

• Accessory

Link cable (3 m) ....................................... 1

Note: The design and specifications are subject to change without notice for improvement.

• Accessories

Extension cable ....................................... 1
Linkage bracket A .................................... 2

Linkage bracket B .................................... 1
Screw for linkage bracket ...................... 12
