53

27. COMPACTFLASH (CF) CARD RECORDING

27.1. Recording

• Use TOA's EV-350R Digital Announcer for CF card recording.
• The table below shows an example of Program/Sentence composition for Messages 1 – 8.

[Setting items and contents]
(1) Set the items in "Program No." (P001 – P008) and "Playback method" columns as shown in the table.

Besides, be sure to set the "Busy output (at repeat interval)" (omitted in the table) for ON (factory-preset).

(2) The contents in "Number of repeats", "Repeat interval", and "Sentence No. (or Silent Section)" are given

for an example.

(3) Determine the optimum "Output level" for each Program by performing the operation.

(Factory-preset level: Graduation 6)

Note: The VM amplifier ignores the following settings programmed by the EV-350R.

(1) Program title, Sentence title
(2) Output (1 and/or 2)
(3) The setting contents to be registered in the EV-350R unit, not in the CF card. (See the item marked

(*

2

) in the "Summarized Operational Functions" on page 15 of the "EV-350R OPERATING

INSTRUCTIONS.")

Refer to the "Digital Announcer EV-350R Operating Instructions" for terminologies and recording method.

[CF Card (card adapter required)]
• Use the supplied CF card.
• Be sure to keep 10-second or longer unrecorded portion on the card because it is used for controlling the

EV-200M board's surveillance function.

• Place the CF card in the CompactFlash card adapter, then insert the adapter into the memory card slot on

the EV-350R's front panel.

Caution
• When the EV-200M is mounted, never move the unit from one place to another with the Flash Card inserted

because the EV-200M or the CompactFlash card may fail.

• Avoid inserting or withdrawing the CompactFlash card while the unit is alive.

27.2. Message Program/Sentence Composition Example

Remarks

Activation from
Remote Microphone
or Message
activation input
(CONTROL I/O)
Alert message
Evacuation message
Pre-recorded chime

VM unit's

Message No.

Message 1
Message 2
Message 3
Message 4
Message 5
Message 6
Message 7
Message 8

Playback

method

Continuous
Program
Playback

Repeat
Playback
Continuous
Program
Playback

Number

of repeats

––
––
––
––
––

5 times
Endless

––

Repeat
interval

––
––
––
––
––

0 second
0 second

––

Sentence No.

(or Silent Section)

A001, A002, M003, A003
A011, A012, M002, A013
A021, A022, M002, A023
A031
A041
A051, M001, A052, M002
A061, M001, A062, M002
A071

Program

No.

P001
P002
P003
P004
P005
P006
P007
P008
