33

8 Digital Communication Interface

Interface Commands

Command Description

Command
Format

Command
Example

Returned

Returned
Example

Acceptable
Values

Calibration Parameters Menu

Read R0 calibration parameter

r[0]

r

r0: 999.999

r0: 100.578

Set R0 calibration parameter to

n r[0]=n

r=100.324

100 to 105

Read ALPHA calibration
parameter

al[pha]

al

al: 9.9999999

al: 0.0038573

Set ALPHA calibration parameter
to

n

al[pha]=n

al=0.0038433

0.002 to 0.006

Read DELTA calibration
parameter

de[lta]

de

de: 9.9999

de: 1.507

Set DELTA calibration parameter de[lta]=n

de=1.3742

0.5 to 1.9

Read BETA calibration parameter be[ta]

be

Be: 9.999

be:0.342

—25 to 25

Set BETA calibration parameter

be[ta]=n

be=0.342

Miscellaneous

Read firmware version number

*ver[sion]

*ver

ver.9999,9.99

ver.9009,1.21

Read structure of all commands

h[elp]

h

list of commands

Read ALL operating parameters

all

all

list of parameters

Legend:

[] Optional Command data

{} Returns either information

n Numeric data supplied by user

9 Numeric data returned to user

x Character data returned to user

Note:

When DUPLEX is set to FULL and a command is sent to READ, the command is returned followed by a
carriage return and linefeed. Then the value is returned as indicated in the RETURNED column.

Preface all commands with either C: (for cold side) or H: (for hot side). If the C: or H: is left off, the returned value is for the hot side.

The returned command has either a ‘C’ or an ‘H’ before the colon depending on which side was queried.

9009 Communication Commands Continued
