5.3

Accessories

The following inserts are available for the 9009 calibrator. Inserts may be used
with either the hot or cold temperature wells.

Model

Description

3102-0

Blank Insert

3102-1

1/16” (1.6 mm) Insert

3102-2

1/8” (3.2 mm) Insert

3102-3

3/16” (4.8 mm) Insert

3102-4

1/4” (6.4 mm) Insert

3102-5

5/16” (7.9 mm) Insert

3102-6

3/8” (9.5 mm) Insert

3102-7

7/16” (11.1 mm) Insert

3102-8

5/32” (4.0 mm) Insert

15

5 Parts and Controls

Accessories

Figure 2 Constant Temperature Block
Assembly
