9009 Industrial Dual-Block Calibrator
User’s Guide

32

Command Description

Command
Format

Command
Example

Returned

Returned
Example

Acceptable
Values

Display Temperature

Read current set-point

s[etpoint]

s

set: 9999.99 {C or F}

set: 150.00 C

Set current set-point to n

s[etpoint]=n

s=350

Instrument
Range

Read temperature

t[emperature]

t

t{h or c}: 9999.99 {C or
F}

th: 55.66 C

Read temperature units

u[nits]

u

u: x

u: C

Set temperature units:

u[nits]=c/f

C or F

Set temperature units to Celsius

u[nits]=c

u=c

Set temperature units to
Fahrenheit

u[nits]=f

u=f

Read scan mode

sc[an]

sc

sc: {ON or OFF}

sc: ON

Set scan mode

sc[an]=on/off

sc=on

ON or OFF

Read scan rate

sr[ate]

sr

srat: 99.9 {C or F}/min

srat:12.4 C/min

Set scan rate

sr[ate]=n

sr=1.1

0.1 to 99.9

Secondary Menu

Read proportional band setting

pr[opband]

pr

pb: 999.9

pb: 15.9

Set proportional band to

n

pr[opband]=n

pr=8.83

Depends on
Configuration

Read heater power

(duty cycle)

po[wer]

po

po: 999.9

po: 1.3

Configuration Menu

Operating Parameters Menu

Read High Limit

hl

hl

hl: 999

hl: 350

Set High Limit

hl=

n

hl=350

Cold 25 to 126,
Hot 50 to 350

Serial Interface Menu

Read serial sample setting

sa[mple]

sa

sa: 9

sa: 1

Set serial sampling setting to

n

seconds

sa[mple]=n

sa=0

0 to 999

Set serial duplex mode:

du[plex]=f[ull]/h[alf]

FULL or HALF

Set serial duplex mode to full

du[plex]=f[ull]

du=f

Set serial duplex mode to half

du[plex]=h[alf]

du=h

Set serial linefeed mode:

lf[eed]=on/of[f]

ON or OFF

Set serial linefeed mode to on

lf[eed]=on

lf=on

Set serial linefeed mode to off

lf[eed]=of[f]

lf=of

Table 2 9009 Controller Communications Commands
