7.9.1 BAUD Rate
The BAUD rate is the first parameter in the menu. The BAUD rate setting de-
termines the serial communications transmission rate.
bAUd
Flashes and then displays the current setting
2400 b
Current BAUD rate setting
The BAUD rate of the serial communications may be programmed to 300, 600,
1200, 2400 (default), 4800, or 9600 BAUD. Use “UP” or “DOWN” to change
the BAUD rate value.
4800 b
New BAUD rate
Press “SET” to set the BAUD rate to the new value or “EXIT” to abort the op-
eration and skip to the next parameter in the menu.
7.9.2 Sample Period
The sample period is the next parameter in the serial interface parameter menu.
The sample period is the time period in seconds between temperature measure-
ments transmitted from the serial interface. If the sample rate is set to 5, the in-
strument transmits the current measurement over the serial interface
approximately every five seconds. The automatic sampling is disabled with a
sample period of 0.
SPer
Flashes and then displays the current setting
SP= 1
Current sample period (seconds) setting
Adjust the value with “UP” or “DOWN” and then use “SET” to set the sample
rate to the displayed value.
SP= 60
New sample period
7.9.3 Duplex Mode
The next parameter is the duplex mode. The duplex mode may be set to full du-
plex or half duplex. With full duplex any commands received by the calibrator
via the serial interface are immediately echoed or transmitted back to the device
of origin. With half duplex the commands are executed but not echoed.
dUPL
Flashes and then displays the current setting
d=FULL
Current duplex mode setting
