100.0 C Well temperature in degrees Celsius
S
Access set-point memory
1. 25 Set-point memory 1, 25.0°C currently used
To change the set-point memory press “UP” or “DOWN”.
4. 120 New set-point memory 4, 120.0°C
Press “SET” to accept the new selection and access the set-point value.
S
Accept selected set-point memory
7.2.2 Set-point Value
The set-point value may be adjusted after selecting the set-point memory and
pressing “SET”.
4 120 Set-point value in °C
If the set-point value is correct, hold “EXIT” to resume displaying the well
temperature. Press “UP” or “DOWN” to adjust the set-point value.
125.0 New set-point value
When the desired set-point value is reached press “SET” to accept the new
value and to access the temperature scale units. If “EXIT” is pressed, any
changes made to the set-point are ignored.
S
Accept new set-point value
7.2.3 Temperature Scale Units
The temperature scale units of the controller can be set by the user to degrees
Celsius (°C) or Fahrenheit (°F). The units are used in displaying the well tem-
perature, set-point, and proportional band.
Press “SET” after adjusting the set-point value to change display units.
Un= C Scale units currently selected
Press “UP” or “DOWN” to change the units.
Un= F New units selected
21
7 Controller Operation
Temperature Set-point
