5
FieldPilot ®
KIT CONTENTS
Unpack the installation kit and identify the required parts.
Item Part Number Description Quantity
A 32-04040 Switch, Engage/Disengage ......................................................................................1
B 350-0037 Washer, Flat, 3/8” SST .............................................................................................2
C* 35-02151 Valve, FieldPilot, CC LS ...........................................................................................1
C* 35-02180 Valve, FieldPilot, CC LS, PWM ................................................................................1
D 45-05690 Cable, Sensor EXT. 5’ ..............................................................................................2
E 45-07703 Harness, SCM .........................................................................................................1
F 45-10103 Harness, Valve .........................................................................................................1
G 60-01018 Washer, Flat, 1/2” SST .............................................................................................1
H 60-04087 Bolt, Hex- 3/8-16 x 3-1/4” SST .................................................................................2
I 60-04114 Bolt, Hex, M12 -1.75 x 45mm SST ..........................................................................1
J 60-07027 Nut, NyLock 3/8-16, SST .........................................................................................2
K 65-05162 Bracket, Hyd Block Mnt ...........................................................................................1
L 68-01217 Hose, Hyd - 3/8” x 100, #6FORF x #8FJIC 90º .......................................................2
M 68-01218 Hose, Hyd - 3/8” x 22”, #6FORF x #8FORF 90º ......................................................2
N 68-01219 Hose, Hyd - 1/4” x 80”, #6FORF x #6FORF 90º ......................................................1
O 68-02026 Adapter, Hyd Run Tee - #8 ORF ..............................................................................2
P 68-02074 Adapter, Hyd 90º - #6MORF x #6MORB .................................................................5
Q 68-02092 Adapter, Hyd 45º - #8MJIC x #8FJIC .......................................................................1
R 68-02118 Adapter, Hyd - 14mmMORB to #6MORF ................................................................1
S 68-02133 Adapter, Hyd - #8MJIC x M22 x 1.5 Male x 15mm tube ..........................................2
T 90-50013 Cable Tie Kit, 15 ......................................................................................................1
U 91-07011 Steering Wheel Switch Kit .......................................................................................1
V 98-05189 Installation Manual, JD 6x20, 7x20 SF ....................................................................1
W 45-05396 Power Cable, 3 POS AMP .......................................................................................1
* The valve included depends upon which vehicle kit was ordered.Item Illustrations
