4. PrePare counterBalance ValVe
Make sure the Counterbalance Valve (G) is clean. Work on a clean bench. Remove the plastic plugs and
install adapters (AA) in the C1 and C2 ports. Install adapters (BB) in the V1 and V2 ports.
Figure 1-5: Prepare Counterbalance Valve
5. install counterBalance ValVe Mounting Bracket
On the right side of the machine on the frame, locate the existing threaded hole. Use parts (J & K) to
mount the bracket (P) on the inside of the frame.
Figure 1-6: Install Counterbalance Valve Mounting Bracket
AA AA
p
J, K
BB BB
