17
FieldPilot ®
98-05107 R2
13. recoMMended electronic installation
The Steering Control Module (SCM) should be mounted securely to the floor of the cab. The control console can
be mounted to the operator’s preference. The GPS antenna should be mounted as far forward as possible on top
of the cab on a metal surface of at least 4” square.
14. VeriFY oPeration oF hYdraulics and set the steering
control rate
Clean and pick up the area around the vehicle and make certain that it is safe to operate. Start the engine and
check hydraulic connections for leaks. Rotate the steering wheel from one extreme to the other and back to
center, check for leaks. While steering through the extremes of movement, check the cables and hoses for wear
points and strain, adjust as necessary.
The final oil flow rate adjustment is accomplished through the Matrix console. The
target lock to lock time is 5 seconds and the valve frequency is 110. Refer to the Matrix
manual for further instructions.
NOTE: To activate the manual overrides, a tool such as a small screwdriver must be inserted into the end of the
coil to depress the override button.
WARNING: PINCH POINT HAZARD! To prevent serious injury or death, avoid unsafe practice while
manually operating hydraulic steering circuits. Keep others away and stay clear of mechanical steering
linkages.
15. coMPlete electronic installation
Refer to the owner’s manual supplied with the automated steering system to complete the electronic installa¬tion
and setup.
