FieldPilot ®
installation
If there are questions concerning the installation of the FieldPilot system on this vehicle, or due to the
changes in component specifications the parts supplied in the kit are not exactly as presented in this
document, please contact your dealer or TeeJet Customer service representative for clarification
before installation. TeeJet Technologies is not responsible for misuse or incorrect installation of the system.
NOTE: BE VERY CAREFUL TO ABSOLUTELY SECURE ALL CABLES AND HOSES SO THAT THEY DON’T
INTERFERE WITH THE MANY MOVING PARTS OF THE MACHINE!
overview of the Machine
• The FieldPilot valve will mount on the left side of the machine.
• All hydraulic connections will be made at the orbital
• The GPS antenna will mount on the cab.
• The cables will enter the rear of the cab.
NOTE: All references to left and right are stated as if the user is seated in the driver’s seat.
Figure 1-2: Overview of the Machine
Gps
Fieldpilot
Valve
