FieldPilot ®
Kit CoNteNts
Unpack the installation kit and identify the required parts.
Item Part Number Description Quantity
A 32-04040 Switch, Engage/Disengage ......................................................................................1
B 350-0037 Washer, Flat - 3/8″ SST ..........................................................................................2
C 350-0042 Washer, Split 5/16” SST ...........................................................................................2
D 35-01005 Hyd. Check valve, 5psi check ..................................................................................1
E 35-02180 Valve, Fieldpilot, PWM, CC, LS ..............................................................................1
F 45-07703 Cable, SCM to Valve Interface Cable .....................................................................1
G 45-10103 Cable, Hydraulic Valve Interface .............................................................................1
H 60-04011 Bolt, Hex- M8 -1.25 x 20mm SST ............................................................................2
I 60-04087 Bolt, Hex- 3/8-16 x 3-1/4” SST .................................................................................2
J 60-07027 Nut, NyLock 3/8-16, SST .........................................................................................2
K 65-05176 Bracket, Hyd. Mount ................................................................................................1
L 68-01127 Hose, Hyd. - 3/8” x 49”, #6FJIC x #6FJIC 90º .........................................................1
M 68-01188 Hose, Hyd. - 3/8” x 102”, #6FJIC x #8FJIC ..............................................................2
N 68-01189 Hose, Hyd. - 1/2” x 24”, #8FJIC x #12FJIC ..............................................................2
O 68-02001 Adapter, Hyd. - #8MJIC x #6MORB .........................................................................2
P 68-02009 Adapter, Hyd. Run Tee - #8 JIC ...............................................................................2
Q 68-02011 Adapter, Hyd. Run Tee - #12 JIC .............................................................................2
R 68-02019 Adapter, Hyd. - #6MJIC x #6MORB .........................................................................3
S 68-02022 Adapter, Hyd. Run Tee - #6 JIC ...............................................................................1
T 68-02074 Adapter, Hyd. 90º - #6MORF x #6MORB ................................................................1
U 68-02093 Adapter, Hyd. 90º - #8MJIC x #8FJIC ......................................................................2
V 68-02110 Adapter, Hyd. - #6FORF x #6MORB .......................................................................1
W 68-02134 Adapter, Hyd. - #8MJIC x M18 x 1.5 Male x 12mm tube .........................................2
X 68-02136 Adapter, Hyd. - #8FJIC x #8MBSPP (1/2-14) ..........................................................2
Y 68-02138 Adapter, Hyd. - #12MJIC x 18MM Standpipe ..........................................................2
Z 68-02139 Nut, Compression - 18MM Tube (M26 x 1.5) ...........................................................2
