www.teejet.com
11
FieldPilot
®
3. install the FieldPilot ValVe
(YOU MAY WISH TO PERFORM THIS STEP AFTER THE HOSES ARE CONNECTED TO THE
FIELDPILOT VALVE).
Use parts
(B, I, & J)
to mount the FieldPilot Valve
(E)
to the bracket
(K)
.
Figure 1-4: Install the FieldPilot Valve
B, i, & J
4. PrePare and install the check ValVe
Install adapter
(R)
in the exit port of the check valve
(D)
as shown. Install adapter
(V)
in the inlet port of the
check valve. Connect the end of the check valve with adapter
(V)
to the fitting in the LS port of the FieldPilot
Valve as shown.
Figure 1-5: Install Pressure Hose
r
d
V
Flow direction
ls port
