www.teejet.com

16

FieldPilot

®

N

8. install the Pressure hose

FieldPilot is the Only Function Using the Power Beyond Valve.

Install hose

(N)

from adapter

(Y)

to the P port on the FieldPilot Valve.

Figure 1-10: Install the Pressure Hose

N
