6. install the tank, Pressure, and load sense adaPters
Locate the Tank, Pressure, and Load Sense ports on the back of the machine. Remove the nut and plug from
each port. Parts
(Y, Z & AA)
will be used to convert the 26mm Tank and Pressure Ports to JIC fittings.
Slide part
(Z)
and then
(AA)
onto part
(Y)
as shown. Then slide part
(Y)
as far into the P and T ports as
possible. Hold part
(Y)
with your hand as you tighten part
(Z)
onto the port. When you can no longer keep
part
(Y)
from turning with your hand, tighten the nut
(Z)
one more complete revolution. Install adapter
(CC)
on the LS port.
NOTE: Images on next page.
