TeeJet FIeldPilot Install AGCO RoGator 1254 - Manual (Page 5)

www.teejet.com
4
FieldPilot ®
Item Part # Description Illustration
C 35-02182 Valve, FieldPilot PWM,
4.0GPM, OC
D 45-07703 Harness, SCM
SCM Power I/O
45-07703
DC: xx/xx
Valve Output
Power
E 45-10103 Harness, Valve
A
B
45-10103
DC: xx/xx
F 60-04089 Bolt, Hex- 3/8-16 x 3-3/4"
SST
G 60-07027 Nut, NyLock 3/8-16, SST
H 65-05134 Bracket, Hyd. Block Mount
I 68-01098 Hose, Hyd. - 1/2" x 64",
#8FJIC x #8FJIC 90º
