10
FieldPilot ®
4. install the excess Flow hose
Disconnect the existing EF hose from the priority valve. Reroute this hose to the EF port on the FieldPilot
Valve.
Figure 1-5: Install the Excess Flow Hose
original eF Hose original eF Hose
original eF Hose
