FieldPilot ®
iNstAllAtioN
If there are questions concerning the installation of the FieldPilot system on this vehicle, or due to
the changes in component specifications the parts supplied in the kit are not exactly as presented
in this document, please contact your dealer or TeeJet Customer service representative for
clarification before installation. TeeJet Technologies is not responsible for misuse or incorrect installation of
the system.
NOTE: BE VERY CAREFUL TO ABSOLUTELY SECURE ALL CABLES AND HOSES SO THAT THEY
DON’T INTERFERE WITH THE MANY MOVING PARTS OF THE MACHINE!
Overview of the Machine
• The FieldPilot valve will mount underneath the cab.
• The Tank and Steering lines will tee in at the orbital.
• The Pressure and LS lines will tee in at the main hydraulic block located on the right side of the
machine.
• The GPS should mount at the front edge of the cab.
NOTE: All references to left and right are stated as if the user is seated in the driver’s seat.
Figure 1-2: Overview of the Machine
Gps
Fieldpilot
Valve
Hydraulic Block
and p & ls
Connections
